Art.nr: LZ-159311

Lazer Carbon-6 Spot Gen3

728 EUR incl VAT

Leverans inom 4-7 dagar (Available on back-order)

  • Fast deliveries
  • Secure payments
  • Ångerrätt 30 dagar
Product information
Size mm 315x99x63
LED Chips Power W 85
Colour temperature 5000K
Moisture protection value (IPXX) IP68
Light image Spotlight
Volt (V) Multivolt, 10, 12, 16, 18, 24, 28, 30, 32
Power consumption 5.9A@14.4V
Lamp cap / Contact DT4
Authorisation ECE, R10, R149

Full product information

The third generation of Carbon-6 LED automotive lamps

Lazer's Carbon range sets a whole new standard for auxiliary lighting in the world of motorsport!

Through extensive testing and feedback from the very highest levels of rally, track and off-road motorsport, the colour temperature of the LEDs has been carefully selected to provide maximum definition and sharpness. The unique design of both the housing and internal electronics, which includes rear-facing LEDs, provides greater light utilisation, reduced scatter and a more homogeneous light distribution.

The high-intensity 11W diodes in the Carbon-6, as well as the 3W Matrix LEDs, fine-tuned for the specific requirements of motorsport, together provide an outstanding light performance with ultra-reflective vacuum metallised boost optics. The Carbon-6 is available with both Spot and Drive light patterns. Thanks to the ultra-lightweight lamp housing, available in both carbon fibre and 3D-printed material, the light weighs just 420 g, giving the light an impressive power-to-weight ratio previously unseen in automotive lighting.

The Carbon-6 is compatible with Lazer's Race Dashboard Controller which allows the ramps to be set to different modes; fog mode, adaptive mode (a secondary beam moves up or down depending on braking and acceleration), E-branded mode and E-boost mode.

LED: 6 x LED

Teoretiska Lumen: 9360 lm

Volt: 10-32V

Effect: 85W Boost mode | 22W E-Mark mode

Strömförbrukning (vid 14,4 V): 5,9A Boost mode | 1,5A E-Mark mode

Räckvidd: 1 Lux @ 768 m Boost mode | 1 Lux @ 344 m E-Mark mode

Colour temperature: 5000K

Ljusbild: Spot

Moisture protection: IP68

Anslutning: DT4

Mått & Vikt: 315x99x63 mm | 0.45kg

Certifikat: ECE R10, ECE R149

Saltspray testad: ISO 9227

Dumpbelastningsskydd: ISO 7637-2

Garanti: 5år
